Top-hung movable glass walls
Revolutionary Design Features
Our folding partition walls combine cutting-edge engineering with thoughtful design to deliver unmatched performance
No Floor Rail Design
Eliminates tripping hazards and simplifies floor cleaning. Enhances accessibility and maintains uninterrupted floor aesthetics.
Top-Hung Support System
Panels are suspended from an overhead aluminum or steel track, ensuring stability without visible floor clutter.
Supports smooth sliding or folding operation (depending on configuration).
Bottom Floor Bolt Positioning
Each glass panel is secured via discreet floor bolts, providing precise alignment and lateral stability.
Customizable Configurations
Available in sliding, folding, or fixed-panel designs. Compatible with various glass types:
- Clear, frosted, or tinted glass
- Laminated glass options
- 6-12 mm thickness choices
Acoustic & Thermal Performance
Integrated seals and gaskets provide enhanced sound insulation (STC ratings up to 42 dB).
Energy-efficient glass options minimize heat transfer for improved thermal efficiency.
Exceptional Operational Advantages
Our folding glass walls offer unprecedented flexibility and ease of use for modern commercial and residential spaces.
Top Hung Design
No floor track required for smooth operation
Smooth Operation
Effortless sliding and folding movement
Flexible Configuration
Hinged together or moved individually
Convenient Parking
Panels can be parked away from openings
Automatic Locking
Bolts release automatically when moved
Elegant & Secure
Combines aesthetics with strength
Maximum Glass Area
Minimal top and bottom profiles
Technical Specifications
Comprehensive technical details of our folding glass wall systems
| Folding Glass Wall - Up to 5m high | |
|---|---|
| Frame Material | Aluminum alloy (6063-T5) , Anodized or powder coated |
| Glass Specifications | Tempered, Laminated or Insulated glass 8mm + 8mm thickness Coatings: Low-E, UV-protective or tinted options |
| Panel Height | Up to 5,000mm (16.4ft) |
| Panel Width | 1,200 - 1,500mm (4-5ft) per sliding panel |
| Track System | Top hung support without floor track Aluminum Track, Anodized Load capacity: Up to 1,000kg per panel |
| Panel Positioning | Materials: Silicone or EPDM Actuated: Floor bolt on panel edge |
| Thermal Performance | U-value: 1.0 - 1.5 W/m².K (with insulated glass) Air Infiltration: ≤1.5CFM/ft²@75pa |
| Acoustic Performance | Sound transmission class (STC): Up to 42 dB |
| Weather Resistance | Water Penetration: Up to 600Pa Wind Load Resistance: Up to 3,000Pa |
| Fire Rating | Up to 60-120 Min (Optional fire-rated glass and frames) |
